VERTICAL FLAMMABILITY TESTER – UL 94
To determine the ease of flammability of the plastic materials used for parts in appliances and devices. They are intended to serve as a preliminary indication of their acceptability with respect to flammability for a particular application.
Our VERTICAL FLAMMABILTY TESTER consists of a closed chamber made of CRCA mild steel sheet. A laboratory burner having specified diameter of opening is mounted on the guide bar which can be slide forward and backward direction. The burner can be rotated about 45 degree from vertical during testing.
The equipment is finished with corrosion resistant finish.
Chat on WhatsApp
Description
| Specification | Details |
|---|---|
| Model No. | GTX-FUL94 |
| Dimensions of Test Chamber | 500 × 400 × 450 mm |
| Diameter of Burner Opening | 9.5 ± 0.3 mm |
| Flame Application Timer | 99.99 Seconds |
| Flaming Timer | 999.9 Seconds |
| Distance Between Specimen Lower Edge and Burner Top | 20 ± 1 mm |
Features:
- Designed for flammability testing of plastic materials.
- Accurate burner assembly as per UL 94 requirements.
- Digital flame application timer.
- Digital flaming timer for precise test observation.
- Robust test chamber construction.
- Suitable for horizontal and vertical flammability evaluations.
- User-friendly operation and reliable test results.
Related Standards:
- UL 94:2001 – Tests for Flammability of Plastic Materials for Parts in Devices and Appliances.
