HTHP GLYCERIN BATH BEAKER DYEING MACHINE

HTHP GLYCERIN BATH BEAKER DYEING MACHINE

It is a versatile, compact and maintenance free equipment which is suitable for dyeing of polyester, cotton and any form of fiber or blended yarn and fabric. It can also be used to carry out dyeing process at atmospheric pressure also.     Having 12 pot of 500 ml, Inner chamber and outer body complete in S.S. with digital temperature indictor cum controller, cooling arrangement and reverse forward motion to maintain uniformity inside the jar.
Category:
WhatsApp Chat on WhatsApp

Description

HTHP Glycerin Bath Beaker Dyeing Machine Series

Available Models:
GTX-HG1-A (12 × 250 ml),
GTX-HG1-B (12 × 500 ml) &
GTX-HG1-C (8 × 250 ml + 1 × 5L)

Specification GTX-HG1-A GTX-HG1-B GTX-HG1-C
Beaker Configuration 12 × 250 ml 12 × 500 ml 8 × 250 ml + 1 × 5L
Main Bath Material SS-304 Grade SS-304 Grade SS-304 Grade
Outer Body Material SS-304 Grade SS-304 Grade SS-304 Grade
Beaker Material SS-316 Grade SS-316 Grade SS-316 Grade
Wall Thickness 4 mm (Withstands Pressure up to 6 kg/cm²) 4 mm (Withstands Pressure up to 6 kg/cm²) 4 mm (Withstands Pressure up to 6 kg/cm²)
Heating System Electrical Heating, 4.5 kW, Glycerin Heating Medium Electrical Heating, 4.5 kW, Glycerin Heating Medium Electrical Heating, 4.5 kW, Glycerin Heating Medium
Cooling System Cooling Pipe with Water Circulation Cooling Pipe with Water Circulation Cooling Pipe with Water Circulation
Temperature Control Digital Temperature Indicator Cum Controller / Programmer Digital Temperature Indicator Cum Controller / Programmer Digital Temperature Indicator Cum Controller / Programmer
Programming Capacity Up to 99 Programs Up to 99 Programs Up to 99 Programs
Construction Complete Stainless Steel Construction Complete Stainless Steel Construction Complete Stainless Steel Construction
Special Features Tank, Beaker & Gear Box Assembly with Smooth & Leak-proof Operation Tank, Beaker & Gear Box Assembly with Smooth & Leak-proof Operation Tank, Beaker & Gear Box Assembly with Smooth & Leak-proof Operation
