GEO SYNTHETICS CBR PUNCTURE RESISTANCETESTER
This standard specifies a method for the determination of the puncture resistance by measuring the force required to push a flat ended plunger through the geo synthetics the test is normally carried out on dries specimens Conditions in the specified atmosphere.
The specimen is clamped between 2 steel rings a plunger is advanced at a constraint rate to the center of the specimen&
Perpendicularly to it. The push through force, push through displacement are recorded.
Chat on WhatsApp
Description
| Specification | Details |
|---|---|
| Model No. | GTX-CBR-2T |
| Capacity | 2 Ton |
| Display | Digital |
| Load Accuracy | ±0.5% |
| Traverse Speed | 50 ± 5 mm/Min |
| Displacement Accuracy | 0.1 mm |
| Clamping Ring ID | 150 mm |
| Testing Fixtures | One Set of Puncture Strength Grip & One Set of Burst Strength Grip |
Features:
- Digital load and displacement display.
- High accuracy load measurement (±0.5%).
- Suitable for puncture and bursting strength testing.
- Heavy-duty 2 Ton load capacity.
- Supplied with puncture and burst strength testing fixtures.
- Reliable and repeatable test results.
Related Standards:
- IS 13162 Part-4:1996
- ASTM D3786
- IS 16078:2013
- ISO 12236:2006
